MagnaFlow 20-23 Jeep Gladiator JT 3.6L Overland Series Cat-Back Exhaust
MagnaFlow 20-23 Jeep Gladiator JT 3.6L Overland Series Cat-Back Exhaust
A$2,259.71
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
The MagnaFlow® Jeep Gladiator Overland Series™ Cat-Back Performance Exhaust System #19621 brings superior ground clearance, dyno-proven performance and our signature exhaust sound to your Jeep Gladiator equipped with the 3.6L engine option. This kit’s direct-fit configuration is designed for easy installation and intended to replace your rig’s OEM exhaust components from near the catalytic converter on back. #19621 features 3” mandrel bent main piping that passes through an 18” straight-through oval bodied muffler and NDT (No Drone Technology) tuned chamber before terminating in a high-clearance tucked tailpipe to the rear of the driver’s side. The integration of MagnaFlow®’s NDT technology allows this exhaust system to be enjoyed at highway speeds without any unwanted droning noises that can occur in competing exhaust systems. The kit’s high clearance design and improved departure angles versus the stock system allows your truck to handle any terrain more easily. This Jeep Gladiator exhaust system also offers unmatched tunability thanks to the accessory port on the integrated muffler, which allows for different modules to be attached. Exhaust kit #19621 includes an NDT module, which can be attached to that port to further mitigate certain droning frequencies, perfect for longer trips. Alternatively, the port can be covered with the included pipe cap which allows for a more free-breathing engine note to make its way through the pipes. This performance exhaust system is made of durable stainless steel backed by MagnaFlow®’s limited lifetime warranty.
Product Overview
The MagnaFlow Jeep Gladiator Overland Series Cat-Back Performance Exhaust System #19621 brings superior ground clearance, dyno-proven performance and our signature exhaust sound to your 2020-2024 Jeep Gladiator equipped with the 3.6L engine option. This kit’s direct-fit configuration is designed for easy installation and intended to replace your rig’s OEM exhaust components from near the catalytic converter on back. #19621 features 3” mandrel bent main piping that passes through an 18” straight-through oval bodied muffler and NDT (No Drone Technology) tuned chamber before terminating in a high-clearance tucked tailpipe to the rear of the driver’s side. The integration of MagnaFlow’s NDT technology allows this exhaust system to be enjoyed at highway speeds without any unwanted droning noises that can occur in competing exhaust systems. The kit’s high clearance design and improved departure angles versus the stock system allows your truck to handle any terrain more easily. This Jeep Gladiator exhaust system also offers unmatched tunability thanks to the accessory port on the integrated muffler, which allows for different modules to be attached. Exhaust kit #19621 includes an NDT module, which can be attached to that port to further mitigate certain droning frequencies, perfect for longer trips. Alternatively, the port can be covered with the included pipe cap which allows for a more free-breathing engine note to make its way through the pipes. This performance exhaust kit is made of durable, corrosion resistant stainless steel and produced using advanced CNC precision robotic manufacturing techniques, all backed by MagnaFlow’s limited lifetime warranty.
Features and Benefits
- No-Drone-Technology Allows For A Quiet Cabin
- No-Drone-Technology (NDT) allows for a quiet cabin
- Dyno proven performance
- High clearance exit
Product Details
| 11009: | 5 |
|---|---|
| 11010: | 18 |
| 11011: | 8 |
| 11039: | 4 |
| 11040: | 6 |
| 11041: | 4 |
| 11060: | Straight-Through |
| 11070: | Tuned Chamber |
| Catalytic Converter Quantity: | 0 |
| Clamping Type: | Band Clamp |
| Clamps Included: | Yes |
| Description: | Overland Series Stainless Cat-Back System |
| Exhaust Tip Quantity: | 0 |
| Exhaust Type: | Cat-Back |
| Exit Position: | Driver Side |
| Exit Style: | Single Straight Driver Side Rear |
| Gasket Or Seal Included: | No |
| Hangers Included: | Yes |
| Inlet Inside Diameter: | 3.000 in. |
| Inlet Type: | Clamp-On |
| Main Piping Diameter: | 3 |
| Material: | Stainless Steel |
| Mounting Bracket Included: | No |
| Muffler Body Height Position Front: | 5 |
| Muffler Body Height Position Rear: | 4 |
| Muffler Body Length Position Front: | 18 |
| Muffler Body Length Position Rear: | 6 |
| Muffler Body Material: | Stainless Steel |
| Muffler Body Width Position Front: | 8 |
| Muffler Body Width Position Rear: | 4 |
| Muffler Finish: | Brushed |
| Muffler Quantity: | 2 |
| Muffler Type Position Front: | Straight-Through |
| Muffler Type Position Rear: | Tuned Chamber |
| Muffler Type: | Straight-Through;Tuned Chamber |
| Part Number: | mag19621 |
| Pipe Material: | Stainless Steel |
| Prop 65 Y/N: | No |
| Series: | Overland |
| Tip Diameter: | N/A |
| Title: | MagnaFlow 2020-2025 Jeep Gladiator Overland Series Cat-Back Performance Exhaust System |
| Tubing Diameter: | 3.000 in. |
| Type: | Cat-Back |
| Valve Included: | No |
| WARNING CA Proposition 65: | No |
Part Type
Exhaust System Kit
Features
- Dyno Proven Performance
- High clearance exit
- No-Drone-Technology Allows For A Quiet Cabin
Specifications
- Product Attributes - Brand
- MagnaFlow
- Product Attributes - Manufacturer's Part Number
- 19621
- Product Attributes - Part Type
- Exhaust Systems
- Product Attributes - Product Line
- MagnaFlow Overland Series Performance Exhaust Systems
- Product Attributes - UPC
- 888563181325
- Product Attributes - System Material
- 409 stainless steel
- Product Attributes - System Style
- Cat-back
- Product Attributes - Exhaust Type
- Single
- Product Attributes - Exit Location
- Rear
- Product Attributes - System Finish
- Natural
- Product Attributes - Catalytic Converter(s) Included
- No
- Product Attributes - Intermediate Pipe Diameter (in.)
- 3.00 in.
- Product Attributes - Muffler Included
- Yes
- Product Attributes - Muffler Quantity
- One
- Product Attributes - Muffler Configuration
- Single inlet/Dual outlet
- Product Attributes - Muffler Style
- Perforated tube with packing
- Product Attributes - Muffler Material
- 409 stainless steel
- Product Attributes - Muffler Finish
- Brushed
- Product Attributes - Hardware Included
- Yes
- Product Attributes - Tailpipe Diameter (in.)
- 3.00 in.
- Product Attributes - Tip Included
- No
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold as a kit.
- Product Attributes - Special Attention
- It is illegal to install parts or components that bypass, defeat, or render inoperative the manufacturers’ technology and design necessary to reduce vehicle emissions to meet state and federal Clean Air Act standards.
Reference Information
| Brand Name/s | Magnaflow |
|---|---|
| StreetFX SKU | mag19621 |
| SFX Item ID | 4289210 |
| Supplier Item Code | 4289210 |
| Manufacturer SKU | 19621 |
| Manufacturer UPC | 888563181325 |
| Alternative References | mpe-19621, MFL19621, 3.6L |
