Hedman Street Headers 69390 Headers, Street, Long Tube, Steel, Temporary Paint, Chevy, GMC, 454, Pair
Hedman Street Headers 69390 Headers, Street, Long Tube, Steel, Temporary Paint, Chevy, GMC, 454, Pair
A$1,131.53
IN STOCK! Est Ship 4-7 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
For the price, no other part can give you the horsepower and fuel economy improvements of Hedman headers. They make Hedman Street headers so well that they guarantee them to be free from defects--including cracks in the tubes and welds--for the life of the headers. Hedman Street headers are available uncoated or in Black Maxx or their polished HTC thermal ceramic coated finishes and, as an added bonus, they also come with all necessary gaskets and mounting hardware. Unless otherwise noted, these headers are designed to fit the vehicle as it came from the manufacturer. This includes components like cylinder heads, chassis, steering, motor mounts, body mounts, and bushings, etc. If your vehicle is using aftermarket components, parts from other applications, or custom-altered parts, then it is the installer's responsibility to verify fitment.
Special warning regarding Hedman painted headers only. The paint on these headers is not designed as a final finish; it is designed to protect the headers after the manufacturing process and during shipping. This paint will not withstand the high heat associated with engine break-in, nor will it withstand the heat cycles associated with any type of driving. It is recommended that this protective coating be stripped, and a high heat paint or coating designed for use on headers be applied.
Part Type
88-91 Bb Chevy 4x4
Specifications
- Product Attributes - Brand
- Hedman Hedders
- Product Attributes - Manufacturer's Part Number
- 69390
- Product Attributes - Part Type
- Headers
- Product Attributes - Product Line
- Hedman Street Headers
- Product Attributes - UPC
- 732611693905
- Product Attributes - Header Style
- Long tube one-piece
- Product Attributes - Header Material
- Steel
- Product Attributes - Primary Tube Outside Diameter (in.)
- 1 3/4 in.
- Product Attributes - Header Color
- Temporary non-high temperature paint
- Product Attributes - Flange Style
- Standard
- Product Attributes - Weld-Up
- No
- Product Attributes - Cylinder Head Port Shape
- Round
- Product Attributes - Collector Attachment
- Ball and socket flange
- Product Attributes - Collector Diameter (in.)
- 3.00
- Product Attributes - Collector Reducers Included
- Yes
- Product Attributes - Collector Reducer Exit Diameter
- 2.500 in.
- Product Attributes - Tuned
- No
- Product Attributes - Primary Tube Gauge
- 16-gauge
- Product Attributes - Flange Thickness (in.)
- 0.31 in.
- Product Attributes - Bolts/Studs Included
- Yes
- Product Attributes - Gaskets Included
- Yes
- Product Attributes - Crossover Pipe Included
- No
- Product Attributes - Catalytic Converter(s) Included
- No
- Product Attributes - Motor Mounts Included
- No
- Product Attributes - Transmission Mount Included
- No
- Product Attributes - Quantity
- Sold as a pair.
- Product Attributes - Notes
- The paint applied to these headers is a temporary coating only and is designed to burn off during use. High temperature paint or other high temperature coatings are recommended.
Reference Information
| Brand Name/s | Hedman Hedders |
|---|---|
| StreetFX SKU | hed69390 |
| SFX Item ID | 5071033 |
| Supplier Item Code | 5071033 |
| Manufacturer SKU | 69390 |
| Manufacturer UPC | 732611693905 |
