FAST LS91 High Output Universal External-Core Coil
FAST LS91 High Output Universal External-Core Coil
A$221.85
Available from MFR.
This item is available from the manufacturer's distribution centre. The dispatch timeframe shown is an estimate based on historical order processing and release times for this part. This item is not held in our own warehouse, and actual dispatch timing may vary depending on manufacturer workload and logistics at the time of ordering.
We accept
Description
The I91 Coil is designed for use with FAST high output inductive ignition systems such as the I6 Ignition Control or the XR700 and XR3000 Electronic Conversion Systems. The internal design is optimized to produce a long duration spark coupled with higher voltage output making it ideal for street and performance applications.
Part Type
Ignition Coil
Specifications
- Product Attributes - Brand
- FAST
- Product Attributes - Manufacturer's Part Number
- 730-0891
- Product Attributes - Part Type
- Ignition Coils
- Product Attributes - Product Line
- FAST I91 Inductive Ignition Coils
- Product Attributes - UPC
- 021174021080
- Product Attributes - Coil Style
- Remote mount
- Product Attributes - Primary Resistance
- 0.400 ohms
- Product Attributes - Coil Internal Construction
- Epoxy
- Product Attributes - Coil Wire Attachment
- Male/HEI
- Product Attributes - Coil Color
- Black
- Product Attributes - Maximum Voltage
- 47,000 V
- Product Attributes - Turns Ratio
- 57:1
- Product Attributes - Secondary Resistance
- 4.60K ohms
- Product Attributes - Inductance
- 4.70 mH
- Product Attributes - Peak Current
- 380 mA
- Product Attributes - Spark Duration
- 280 uS
- Product Attributes - Mounting Bracket Included
- Yes
- Product Attributes - Coil Wire Included
- No
- Product Attributes - Ballast Resistor Included
- No
- Product Attributes - Coil Shape
- Square
- Product Attributes - Height (in.)
- 3.000 in.
- Product Attributes - Length (in.)
- 3.750 in.
- Product Attributes - Width (in.)
- 2.500 in.
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Coil is universal. Modifications may be required.
Reference Information
| Brand Name/s | Fast |
|---|---|
| StreetFX SKU | fst730-0891 |
| SFX Item ID | 4085041 |
| Supplier Item Code | 4085041 |
| Manufacturer SKU | 730-0891 |
| Manufacturer UPC | 21174021080 |
| Alternative References | LS91 |
