Description

Developed from our off-road race shocks, FOX Factory Race Series combines race-proven technology with new, cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.

Product Overview

Uncompromised performance through FOX’s patented internal bypass technology delivers the feel of near-endless suspension travel. Exclusive internal bypass technology allows oil to flow around the piston at some points of the stroke – while creating humongous pressure at other points – supporting the vehicle like no other product can. Floating through terrain is accomplished with FOX’s ride zone – combining a race-developed shock piston, internal bypass and Dual Speed Compression adjustment – allowing fine tuning for weight, terrain and speed. Dominate any terrain with the brute strength of 3- and 2.5-inch aluminum bodies, cactus cooler reservoirs and 7/8” shafts with redundant seals, all proven in the harshest of environments under the toughest of conditions.

Features and Benefits

• Redundant Sealing System/Long Lasting Performance
• Performance Tuned Specifically For Raptor
• Finned External Reservoir System Dissipates Heat Fast
• Quick Switch Compression And Rebound Adjusters
• Live Valve Terrain Adaptive Technology
• Black Anodized CNC Machined Aluminum Components
• Durable Zinc Plated Seamless Alloy Body
• Industry-Leading 17-4 H900 Stainless Steel Shaft
• ORB O-Ring Port Fittings Deliver A Superior Seal
• 100% Serviceable And Tunable For Longer Lifespan
• Teflon-Lined Heat-Treated Spherical Bearings

Product Details

Adjuster Type:	Live Valve/Quick Switch Technology (QS3) - Compression and Rebound
Body Diameter (in):	3
Body Material:	Aluminum
Bottom Mount:	Eyelet
California Proposition 65:	! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Compressed Length (in):	20.60
Description:	FACTORY RACE SERIES 3.0 LIVE VALVE INTERNAL BYPASS COIL-OVER (PAIR)-ADJUSTABLE
Extended Length (in):	28.49
FOX CATALOG:	TRUCK
Label Name:	Kit: 19-ON Ford Raptor Front Coilover, Live Valve, Internal Bypass, 3.0 Series, R/R, 7.9", 0-2" Lift
Part Number:	fox883-06-153
Prop 65 Y/N:	Y
Reservoir Type:	Remote
Series:	Factory Race
Shock Stroke:	7.990 in.
Size:	3 in.
Title:	FACTORY RACE SERIES 3.0 LIVE VALVE INTERNAL BYPASS COIL-OVER (PAIR) - ADJUSTABLE
Top Mount:	OEM
Travel (in):	7.89
Type:	Coil-Over Internal Bypass
WARNING CA Proposition 65 Message:	! Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
WARNING CA Proposition 65:	Yes

Kit Options

This item is available as a full kit.
Select a kit option in the following table if you are looking for this item in a bundle form with all associated components.

Kit option/s:

Thumb	SKU	Kit Title
	cmbCAM-110185-K	(1x fox883-09-153, 1x fox883-06-153, 1x cmbCAM-110233-GRY)

Data: v4.2 - Upd: 2026-10-13 15:43:50

Features

Specifications

Product Attributes - UPC

788000424803

Product Attributes - Brand

Fox Shox

Product Attributes - Notes

Reservoir mounting hardware is included.

Product Attributes - Quantity

Sold as a pair.

Product Attributes - Part Type

Coilover Shocks and Struts

Product Attributes - Gas Charged

Yes

Product Attributes - Lower Mount

Eyelet

Product Attributes - Upper Mount

Bracket

Product Attributes - Product Line

Fox Racing Shox 3.0 Factory Race Series Live Valve Internal Bypass QS3 Adjustable Coilover Shocks

Product Attributes - Bushing Color

Black

Product Attributes - Spring Finish

Black

Product Attributes - Internal Design

Monotube

Product Attributes - Bushing Material

Spherical bearing/PTFE

Product Attributes - Hardware Included

No

Product Attributes - Shock Body Finish

Black anodized

Product Attributes - Adjustable Valving

Yes

Product Attributes - Body Diameter (in.)

3.000

Product Attributes - Coilover Shock Type

Triple-adjustable

Product Attributes - Shock Body Material

Aluminum

Product Attributes - Extended Length (in.)

29.12

Product Attributes - Collapsed Length (in.)

21.15

Product Attributes - Coilover Springs Included

Yes

Product Attributes - Manufacturer's Part Number

883-06-153

Product Attributes - Suspension Height Adjustment

0.0-2.0 in. raised

Product Attributes - Adjustable Mounting Bracket Included

No
