Fluidampr Toyota 2JZ I-6 Steel Internally Balanced Damper

SKU: FDR840801

Harmonic Balancers

FDR Dampers - Import

Fluidampr

Fluidampr Toyota 2JZ I-6 Steel Internally Balanced Damper

SKU: FDR840801

Harmonic Balancers

FDR Dampers - Import

Sale ends in Calculating... Tue 13 Oct, 7:01 am AEST

IN STOCK! Est Ship 4-7 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Protect your engine. Modifications can compromise your stock harmonic balancer. Install a Fluidampr performance damper early for best durability. Superior viscous damper design controls harmful torsional vibration across the entire rpm range. Reduce wear on engine components. Reduce risk of crankshaft failure. Improve timing. Unleash lost torque and horsepower. Precision CNC machined and balanced high-grade steel components. Corrosion resistant black zinc finish with engraved timing marks. No maintenance required. Trusted by leading engine builders worldwide. SFI 18.1 certified. Made in USA.

Product Overview

Fluidampr Engine Dampers are designed to control destructive vibrations which are transfered thru the crankshaft. Each time the air/fuel mixture inside a cylinder is ignited, the combustion that occurs creates a torque spike that is applied to the crankshaft through the piston and rod. This torque spike is so severe that it not only turns the crankshaft, it actually twists the crankshaft ahead of its normal rotation and then the crankshaft rebounds. This twisting action is known as torsional vibration. When these torque spikes and forces get into phase with the natural frequency, critical torsional harmonic vibrations occur and can be seriously destructive to the bearings and the crankshaft. Dampers are designed to control those destructive vibrations. Critical harmonic vibrations occur numerous times in a engineâ€™s operating range. Stock rubber and elastomer-type dampers are frequency sensitive â€œtuned absorbersâ€, and work at only one critical frequency. In the case of a stock rubber damper, it is tuned for a factory engineâ€™s critical harmonic vibrations. If you change the mass of pistons, rods, or the crankshaft, you change the natural frequency of the crankshaft assembly; therefore, the stock damper is no longer tuned to the new frequency of vibration, and you may be headed for early failure of expensive engine components. Dampers also create heat while they work, and rubber is a poor dissipator of heat. This heat and the exposure to the elements deteriorates rubber, causing it to crack and change durometer, which then leads to inertia ring slippage, damper failure, uncontrolled torsional vibration, and costly engine parts breakage.

Features and Benefits

Broad RPM range protection.
Reduce risk of crankshaft failure.
Reduce wear on critical engine parts.
Unleash lost torque & horsepower.
No maintenance required.
Superior durability.
SFI 18.1 spec. Race proven for over 35 years.
Made in USA.

Product Details

Year	Make
Bolt and Washer Included:	No
Bore Dia. Min/Max:	1.378 / 1.379
Degree Marking Range:	31 Timing marks 2 degrees apart and one @180 degrees
Degree Markings:	Engraved
Depth:	2.096
Description:	Fluidampr Harmonic Balancer
Drive Belt Type:	Serpentine
Engine Balance:	Internal
Finish:	Black Zinc
Inside Diameter:	1.3783
Keyway Type:	Single
Keyway:	Single
Length:	2.1
Material:	Steel
Mounting Hardware Incl.:	No
Mounting Hole Quantity:	1
O.D.:	8-1/2" (8.500)
Outside Diameter:	8-1/2"
Part Number:	fdr840801
Prop 65 (C, R, or CR):	CR
Prop 65 - Short Label:	WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Prop 65 Yes/No:	Yes
Pulley Groove Quantity:	6
Safety Rating:	SFI 18.1
Title:	Fluidampr - 840801 - Harmonic Balancer - Fluidampr - Toyota - 1990-2005 - 1JZ / 2JZ I6 - Each
WT. in lbs.()=Rotating weight:	9.7 (6.5 Rwt)
Weight / Rotating Weight:	9.8 lbs / 6.5 lbs

Application Summary

1990-2005 Toyota / Lexus. 1JZ / 2JZ I6. Internal balance.

Part Type

Engine Harmonic Balancer

Data: v4.2 - Upd: 2026-10-10 18:22:36

Features

Broad RPM range protection.
Made in USA.
No maintenance required.
Reduce risk of crankshaft failure.
Reduce wear on critical engine parts.
SFI 18.1 spec. Race proven for over 35 years.
Superior durability.
Unleash lost torque & horsepower.

Specifications

Product Attributes - Brand: Fluidampr
Product Attributes - Manufacturer's Part Number: 840801
Product Attributes - Part Type: Harmonic Balancers
Product Attributes - Product Line: Fluidampr Harmonic Dampers
Product Attributes - UPC: 815293002118
Product Attributes - Engine Balance: Internal
Product Attributes - SFI Rating: SFI 18.1
Product Attributes - Degree Markings: Yes
Product Attributes - Outside Diameter (in.): 8.500
Product Attributes - Keyway Quantity: One
Product Attributes - Harmonic Balancer Material: Steel
Product Attributes - Harmonic Balancer Construction: Fluid
Product Attributes - Harmonic Balancer Color: Black zinc chromate
Product Attributes - Mounting Hardware Included: No
Product Attributes - Quantity: Sold individually.
Product Attributes - Notes: Weight is 9.8 lbs, 6.5 lbs rotating weight.

Reference Information

Brand Name/s	Fluidampr
StreetFX SKU	fdr840801
SFX Item ID	4403636
Supplier Item Code	4403636
Manufacturer SKU	840801
Manufacturer UPC	815293002118
Alternative References	FLU840801, FLU000091, 2JZ, I-6
