FiTech Go EFI 8 PA 1200 HP System Dual Pump/HP Regulator/Go-Spark Fuel Injection Master Kits 96413 Bright Aluminum Finish With Kit
FiTech Go EFI 8 PA 1200 HP System Dual Pump/HP Regulator/Go-Spark Fuel Injection Master Kits 96413 Bright Aluminum Finish With Kit
A$4,830.25
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
When you are getting serious about 4-digit horsepower under your hood with boost or nitrous, Go EFI 8 Power Adder 1,200 hp systems are up to the task. And, with FiTech's master kits you also get a high-pressure fuel delivery solution to take your setup from conventional to EFI.
FiTech Go EFI 8 PA 1,200 hp system Dual Pump/HP regulator/Go-Spark fuel injection master kits pair powerful components designed to support serious horsepower, plus precise fuel pressure and an upgrade to high-powered sparks for improved combustion and power output.
Go EFI 8 Power Adder bolt-on throttle body features eight high-flow injectors capable of fueling up to 1,200 hp. It is supplied with FiTech's Pro-tuning software and features the ability to data-log information. To ensure the best atomization of the fuel injection, the annular discharge design is increased to 20 jet streams to support the fuel volume required under boost, and has a built-in 2.5 BAR MAP sensor to handle the increased boost pressures, along with built-in timing controls based on boost or a nitrous input. The throttle body system includes handheld controller, cable and windshield mount, throttle body vehicle side harness, WBO2 sensor, bung kit, coolant sensor, gasket, mini USB cable, Pro-tuning laptop software, instructions, and warranty info.
Go Fuel dual fuel cell pump modules feature a billet top assembly machined with a 2 in. filler assembly and an internal regulator to maintain 58 psi. No return line is needed, and the module is machined to fit 12-bolt flange fuel cells or can be installed on any tank with the supplied hardware.
Go Fuel High Horsepower regulator will support 2,000 hp. Adjustable from 30 to 70 psi, this larger, dual output model is crafted from billet aluminum and features -6 ORB ports along with a vacuum/boost port. It will accept a gauge.
Go-Spark CDI ignition produces a series of multiple sparks below 2,500 rpm to improve starting, idle quality, and throttle response. At higher rpm, the CD technology continues to deliver full energy sparks through racing rpm to ensure complete combustion of the fuel mixture. Designed for 4-, 6-, and 8-cylinder engines equipped with a distributor, Go-Spark accepts the trigger signal from an HEI, amplifier, points, or 2-wire non-magnetic pickup distributors.
Part Type
Fuel Injection Systems
Specifications
- Product Attributes - Brand
- FiTech Fuel Injection
- Product Attributes - Manufacturer's Part Number
- 96413
- Product Attributes - Part Type
- Fuel Injection Systems
- Product Attributes - Product Line
- FiTech Go EFI 8 PA 1200 HP System Dual Pump/HP Regulator/Go-Spark Fuel Injection Master Kits
- Product Attributes - UPC
- 810128300018
- Product Attributes - Fuel Injection Style
- Throttle body
- Product Attributes - Fuel Injection System Type
- Single 4-Barrel Throttle Body (4150 Flange)
- Product Attributes - Maximum Horsepower with Gas
- 1,200
- Product Attributes - Timing Control Compatible
- Yes
- Product Attributes - ECM Included
- Yes
- Product Attributes - Self Tuning
- Yes
- Product Attributes - User Tunable
- Yes
- Product Attributes - Fuel System Included
- In-tank fuel pump module, returnless
- Product Attributes - Ignition System Included
- Ignition box
- Product Attributes - Power Distribution Included
- None
- Product Attributes - User Interface Included
- 4.5 in. display
- Product Attributes - EGR
- No
- Product Attributes - Transmission Controller Included
- No
- Product Attributes - Metering Style
- Speed density
- Product Attributes - Multi-Port Fuel Rails Included
- No
- Product Attributes - Throttle Body Included
- Yes
- Product Attributes - Throttle Body Mounting Flange
- 4-barrel square bore
- Product Attributes - Venturi Quantity
- 4
- Product Attributes - Venturi Diameter (mm)
- 44.00mm
- Product Attributes - Airflow Rate (cfm)
- 850 cfm
- Product Attributes - Throttle Body Material
- Cast aluminum
- Product Attributes - Throttle Body Color
- Polished
- Product Attributes - Injectors Included
- Yes
- Product Attributes - Injector Size (lbs/hr)
- 80 lbs./hr.
- Product Attributes - Calibration Module Included
- Yes
- Product Attributes - Wiring Harness Included
- Yes
- Product Attributes - Oxygen Sensor Included
- Yes
- Product Attributes - Fuel Pressure Regulator Included
- Yes
- Product Attributes - MAP Sensor Included
- Yes
- Product Attributes - IAT Sensor Included
- Yes
- Product Attributes - TPS Sensor Included
- Yes
- Product Attributes - IAC Motor Included
- Yes
- Product Attributes - Quantity
- Sold as a kit.
- Product Attributes - Notes
- Fuel injection system includes: in tank dual pump module with 2 inch fill, dual output fuel pressure regulator with gauge and fittings, CDI ignition.
Reference Information
| Brand Name/s | Fitech Fuel Injection |
|---|---|
| StreetFX SKU | fif96413 |
| SFX Item ID | 5179088 |
| Supplier Item Code | 5179088 |
| Manufacturer SKU | 96413 |
| Manufacturer UPC | 810128300018 |
