Diamond Pistons Domestic Series 51407-8 Piston and Ring Kit, Series, Forged Aluminum, Dish, 4.040 in. Bore, Mopar, Small Block, Kit
Diamond Pistons Domestic Series 51407-8 Piston and Ring Kit, Series, Forged Aluminum, Dish, 4.040 in. Bore, Mopar, Small Block, Kit
A$3,277.85
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
Diamond Pistons Domestic Series pistons are designed and tested for the high-stresses seen with high-compression, forced induction, or nitrous-fed domestic engines. Engineered with longevity, reliability, and strength, these forged aluminum pistons are specifically designed for your engine to deliver the results you demand.
Diamond Piston Domestic Series pistons feature:
* 3D milling on piston crowns for "ready-to-install" finish
* Generous valve pockets designed to work with stock or oversized valves and various cylinder heads
* Constructed from forged 4032 or 2618 aluminum alloy (where specified)
* Premium 8620 or H-13 steel wrist pins (where specified)
Part Type
Pistons
Specifications
- Product Attributes - Brand
- Diamond Pistons
- Product Attributes - Manufacturer's Part Number
- 51407-8
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- Diamond Pistons Domestic Series Pistons
- Product Attributes - UPC
- 686162218226
- Product Attributes - Piston Rings Included
- Yes
- Product Attributes - Bore (in.)
- 4.040 in.
- Product Attributes - Bore (mm)
- 102.616mm
- Product Attributes - Stroke
- 4.000 in.
- Product Attributes - Engine Stroke Type
- Stroked
- Product Attributes - Rod Length
- 6.123 in.
- Product Attributes - Piston Style
- Dish, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.457 in.
- Product Attributes - Piston Head Volume (cc)
- +20.00cc
- Product Attributes - Wrist Pin Style
- Floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.984 in.
- Product Attributes - Piston Ring Thickness
- 1/16 in. x 1/16 in. x 3/16 in.
- Product Attributes - File Fit
- Yes
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 1/16 in.
- Product Attributes - Top Ring Material
- Ductile iron
- Product Attributes - Top Ring Facing Material
- Plasma-moly
- Product Attributes - Second Ring Thickness
- 1/16 in.
- Product Attributes - Second Ring Material
- Ductile iron
- Product Attributes - Second Ring Facing Material
- Ductile iron
- Product Attributes - Oil Ring Thickness
- 3/16 in.
- Product Attributes - Oil Ring Material
- Stainless steel
- Product Attributes - Oil Ring Tension
- Standard
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold as a set of 8.
- Product Attributes - Notes
- Pistons are 4032 material.
Reference Information
| Brand Name/s | Diamond Pistons |
|---|---|
| StreetFX SKU | dpp51407-8 |
| SFX Item ID | 5528055 |
| Supplier Item Code | 5528055 |
| Manufacturer SKU | 51407-8 |
| Manufacturer UPC | 686162218226 |
