Additional Information

Advanced TIR optics provide high efficiency and focus. High-intensity automotive-type LEDs. Pin-fin heatsink design. Integrated Deutsch-style connector. Durable powdercoated aluminum construction. Engineered and assembled in USA.

Part Type

Fog Light Kit

Features and Benefits

• By directly manufacturing many of our products in St. Louis, Missouri, we are able to carefully control quality, while bringing unique items to market faster than the competition.

Product Details

Product Downloads

#	Document Type	Download
1.	Installation Instructions

Installation guides, warranty details, and other supporting documents are provided by the supplier. In some cases, these files may originate from regions outside your locale, meaning instructions, warranty procedures, and images may not fully align with your specific vehicle or region (e.g., LHD vs. RHD differences, return policies, etc.). If you need clarification, please contact a StreetFX support agent.

• By directly manufacturing many of our products in St. Louis, Missouri, we are able to carefully control quality, while bringing unique items to market faster than the competition.

The Diode Dynamics SS3 Pro Fog Light kits are step up in power from the Sport kits. Each light features a custom molded mounting bracket, plug and play design for quick install, and specially engineered optics. Wire adapters are included to connect the lights to your factory bulb sockets with no additional wiring needed.

The TIR optic in the SS3 LED lights serves as both the optic and main lens for greater efficiency and light output. Thanks to this innovative feature the total intensity of the SS3 is much greater than other LED pods. The lights are available in a cool white or selective yellow color. The white is a 6000K color temperature, which is a true cool white output, and matches most factory LED lighting. The selective yellow is a 3000K color temperature, great for high contrast in poor weather or a distinctive look on the road.

SS3 Pro light kits come in multiple light patterns and power levels. The Driving pattern is designed to supplement your high beams, but it's great for general illumination as well. Rather than a traditional "spot" pattern, the Driving pattern shines in an 18x8 degree spread, providing just enough width to fully illuminate the road ahead at high speeds. The Fog pattern provides an extremely wide field of view, with high-intensity output over an entire 80-degree spread. It serves as a great upgrade for any factory fog lamps and will fully illuminate the area in front of your vehicle.

When installed as a pair and aimed in accordance with your state's regulations, the Driving White pattern meets SAE J581 standard as a Driving/Auxiliary High Beam Light, and the Fog pattern meets SAE J583 standard as a Foglamp, for legal on-road use. Please check your local laws and regulations for aiming, installation, and applicability.

The SS3 Pro LED light kits are available with a distinctive backlight, in a brilliant amber color. This integrated backlight gives you an additional accent light, along with the main beam. The SS3's backlight fully illuminates the TIR optic, providing a more unique and modern look than the small indicator LEDs found in other products. To power the backlight, use the included harness to tap your desired vehicle function.

The SS3 LED fog light kits are available at three different power levels, Sport, Pro, and Max. All options use high-intensity LED emitters, and TIR optics for unmatched focus and overall output. The Sport model uses high-intensity LEDs, and is the best bang for the buck you'll find. The Pro model steps things up in a big way, with double the total power. Finally, the Max model is designed with cutting-edge automotive emitters, for both high power and extreme intensity.

Please note that this information serves as a fitment guide only. For specific fitment questions or clarifications, please contact us, as manufacturers may introduce variations and modifications during model year or regional revisions. While we strive to provide accurate data, fitment details may vary by region; therefore, compatibility outside the listed region and submodel variant cannot be guaranteed.
