Cometic 08-10 Ford 6.4L Powerstroke 103mm Bore .062in MLX-5 Head Gasket

Cometic Gasket

Cometic 08-10 Ford 6.4L Powerstroke 103mm Bore .062in MLX-5 Head Gasket

SKU: CGSC5610-062

Head Gaskets

CG Head Gaskets...

Special Order. Contact for ETA. This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.

We accept

Description

MLX Gaskets utilize an integrated "stopper" layer for combustion chamber sealing

Product Overview

Cometic Head Gaskets are developed with the performance enthusiast in mind. With so many individual requirements for each motor Cometic offers a number of options to suit your specific motor and needs. *MLS* The Cometic MLS gasket is comprised of three layers of Stainless Steel. Cometic uses Stainless steel for increased strength, itÃ¢â‚¬â„¢s ability to rebound and corrosion resistance. The outer layers of the gasket are embossed and coated on both sides with a flouroelastomer rubber based material (Viton) designed to meet the demands of a variety of harsh sealing environments, load conditions and surface finishes. The Viton coating is heat resistant to 2500C or 4820F. The center or shim layer of the gasket is comprised of an uncoated Stainless Steel layer, which can be varied to accommodate multiple thickness requirements. The MLS gasket is ideal for both aluminum heads to cast iron blocks and aluminum heads to aluminum blocks. The composition of MLS will also withstand the shearing forces created by aluminum heads on cast iron blocks. No re-torque is necessary. By design the MLS gasket promotes an even torque load across the sealing surface allowing for measurable reduced bore distortion. *CFM-20* A perforated steel core with an elastomer surface is ideal for head gaskets allowing heat to be drawn evenly across the gasket surface while providing maximum sealing characteristics when exposed to coolants and oils. *COPPER*

Features and Benefits

Embossed Outer Layers Coated w/Viton

Product Details

Bore Diameter:	99mm
Description:	Ford 6.4L Power Stroke Cylinder Head Gasket
Engine Make/Size:	Ford 6.4L
Part Number:	cgsC5610-062
Position:	Left or Right
Prop 65 (C, R or CR):	CR
Prop 65 - Short Label:	Prop_65.jpg
Prop 65 Yes/No:	Yes
Thickness:	.062in
Title:	Cometic Gasket Automotive Ford 6.4L Power Stroke .062 in MLX Cylinder Head Gasket, 103mm Bore, Revision A
WARNING CA Proposition 65 Message:	The state of California has determined that certain chemicals used in the manufacture of this product have been known to cause cancer and birth defects. For more information; visit www.p65Warnings.ca.gov
WARNING CA Proposition 65:	Yes

Part Type

Engine Cylinder Head Gasket

Data: v4.2 - Upd: 2026-09-27 16:32:32

Features

Embossed Outer Layers Coated w/Viton
Improved clamp load around the cylinder without increasing bore distortion

Specifications

Product Attributes - UPC: 191070032425
Product Attributes - Brand: Cometic
Product Attributes - Quantity: Sold individually.
Product Attributes - Bore (mm): 103.000mm
Product Attributes - Lock Wire: No
Product Attributes - Part Type: Head Gaskets
Product Attributes - Bore (in.): 4.055 in.
Product Attributes - Product Line: Cometic MLX Head Gaskets
Product Attributes - Gasket Material: Multi-layer stainless steel
Product Attributes - Compressed Volume (cc): 13.121cc
Product Attributes - Compressed Thickness (in.): 0.062 in.
Product Attributes - Manufacturer's Part Number: C5610-062

Reference Information

Brand Name/s	Cometic Gasket
StreetFX SKU	cgsC5610-062
SFX Item ID	4168316
Supplier Item Code	4168316
Manufacturer SKU	C5610-062
Manufacturer UPC	N/A
Alternative References	CGT-C5610-062, 6.4L, 103mm, .062in, MLX-5
